Pre-order only.

Available sizes: 44, 48, 52, 54, 56, 58, 60

Specifications

Model: Chermin-R
Material: TORAY T800 + T1000 + T1100 Carbon Fiber
Frame Size: 44 / 48 / 52 / 54 / 56 / 58 / 60
SeatPost Clamp Compatibility: 7×7 mm or 7×9 mm Saddle Rails
Upper Headset Bearing: 40*51.8*7, C1.5
Lower Headset Bearing: 40×51.8×8, Outer C3 / Inner C1.5
Bottom Bracket Standard: T47 77-A
Max Chainring Size: 54/40T
Max Tire Clearance: 35C
Tire Size: 700C
Front Wheel Spacing: 12×100 mm (Thru Axle)
Rear Wheel Spacing: 12×142 mm (Thru Axle)
Brake Mount: Flat Mount Disc Brake (140/160mm)
Electronic Groupset Compatibility: Yes
Mechanical Groupset Compatibility: Yes
Rear Hook: UDH 1.0
Frame Weight: 720g (Size 54, Unpainted, Excludes Metal Parts)
Fork Weight: 390±5g（Size 54 RTP）
Integrated Handlebar Weight: 300g
Seatpost Weight: 76g
Seatpost Offset: 7 mm
Spacer Height: 10mm × 2 / 5mm × 2
Stem Cover Height: 10mm / 20mm

Packaging

1x Road Bike Frame
1x Fork
1x Integrated Handlebar
1x Seatpost
